Shortly after its release in 2017, we put the smart lighting system IKEA TRÅDFRI through its paces in our security test. Three years have passed since then: Time to look back and see what has been achieved with this product. Can the system, now renamed IKEA Home smart and with a wider product portfolio, still be recommended as a secure smart home solution? You will find out in the following test report.
In recent years, IKEA has continuously maintained and expanded its smart home programme. In addition to numerous light sources, roller blinds and smart speakers are now also available from the Swedish furniture giant. The Smart Speakers were developed together with Sonos. The Sonos Play:1 was not only the basis, but was also already in our security test.
Unlike the setup of other smart home systems, IKEA Home smart does not require any registration. Once the TRÅDFRI gateway is connected to power and connected to the network via Ethernet cable, the user can add the gateway to the app by scanning the QR code on the gateway. This contains both the MAC address and a security code that is used for encryption in the ongoing communication.
Once the lights have been added through the app, the system is ready for operation. At the time of testing, there is no remote access available yet. However, other solutions such as Homematic IP show that online access is possible without any registration – we therefore hope that IKEA will use similar means if this should ever be implemented.
The TRÅDFRI Gateway, which can be controlled via the app, enables precise control of light color and brightness, setting of timers, grouping of devices in rooms and connection to Amazon Alexa or Google Assistant.
The communication between Android/iOS App and the gateway takes place over UDP and is always DTLS1.2 encrypted, a TLS implementation for UDP. This protects the communication against many threats such as replay attacks by design.
For the communication between app and gateway CoAP (Constrained Application Protocol) is used, a REST-like interface. Various open source products make use of this API and thus integrate the Ikea Home smart system into other smart home solutions.
When the TRÅDFRI Gateway is started, TLS1.2 encrypted communication to webhook.logentries.com takes place. The gateway contacts the server at regular intervals during operation. Logentries.com is an analysis service for log files, which enables IKEA to analyze errors more quickly, for example.
Subsequently, an unencrypted channel is used to check for available firmware updates, which we will discuss in a separate section. Internet communication to servers other than those mentioned did not take place during the test.
As stated in the last test, IKEA has done a good job in developing the IKEA Home smart app and has placed great emphasis on the security of the solution right from the start.
The app data, which includes the needed credentials to access the TRÅDFRI gateway, is securely encrypted using the Android KeyStore. Therefore they are secure from unauthorized access even on rooted devices. For this purpose, the app generates a secure key pair and stores it in the KeyStore provided by Android. With the help of the public key the sensitive information is then stored encrypted.
According to static analysis, the app does not contain any known trackers, so it does not monitor every single action of the user.
The only point where we already wanted an improvement in our 2017 test was the firmware update. As it turned out, unfortunately nothing has changed in this point. We will nevertheless go into the update process in more detail in the following.
At boot time, the TRÅDFRI Gateway checks for new firmware versions both for itself and for all devices connected via Zigbee Light Link ( lights, remote controls, motion sensors etc.). For this purpose, the version_info.json is downloaded via an unencrypted connection, which contains information about all current firmware versions. This was already mentioned by us in the test 3 years ago and we still wonder, why the available HTTPS endpoint, which also got a correct certificiate, is not being used.
We took a closer look at the firmware of the gateway. It mainly contains an ELF (Executable and Linking Format) binary file (for 32bit ARM CPU, Duo Cortex-M3) and is signed.
The signature of the firmware enables the gateway to check whether the firmware has been manipulated. Nevertheless, there are attack scenarios that should not be left out.
By redirecting the DNS requests to a dedicated server or a man-in-the-middle attack, the version_info.json could be manipulated. This could lead to a firmware downgrade attack as well as a denial of service attack. For both attacks, the version number of the available firmware would be incremented. In the case of a downgrade attack, a link to an older firmware would be created, for example with known, exploitable vulnerabilities. In the case of a DoS attack, it would be sufficient to leave the original links in place and increment the version number continuously. This would permanently disable the gateway through reboots and firmware installations.
Both can be resolved by using authenticated DNS answers (DNSSEC) and an encrypted transmission including correct certificate validation.
Projects can be found in the web, which can access the firmware via the contacts of the respective board. This opens up a wide range of possibilities, example links are given below. We name the projects here only for completeness – the methods used are not included in the evaluation.
- Heise: Trådfri: ESP8266-Lampen-Gateway (in German language)
- Github: TRADFRI-Hacking
- Trammell Hudson: Trådfri Hardware Modifications
Anonymised/pseudonymised usage data is shared with partners. Furthermore, an analysis of the usage is carried out by analysis services which are not necessarily located in the European Union, but are certified by the Privacy-Shield.
The Swedish furniture giant has not cut back on the budget for the security of the product, despite its low price. The actually secure product is compromised by downloading the firmware via HTTP, even though the potential danger in private households is probably not worth mentioning. In households with increased security needs, we recommend using a separate network/VLAN.
